Hedman 69840 Elite Ultra-Duty HTC Coated Full Length Headers 1988-95 Chevy/GMC P/U 1500/2500/3500 5.0/5.7L Tube Size: 1-5/8"
Hedman 69840 Elite Ultra-Duty HTC Coated Full Length Headers 1988-95 Chevy/GMC P/U 1500/2500/3500 5.0/5.7L Tube Size: 1-5/8"
Hedman 69840 Elite Ultra-Duty HTC Coated Full Length Headers 1988-95 Chevy/GMC P/U 1500/2500/3500 5.0/5.7L Tube Size: 1-5/8"
hedman

Hedman 69840 Elite Ultra-Duty HTC Coated Full Length Headers 1988-95 Chevy/GMC P/U 1500/2500/3500 5.0/5.7L Tube Size: 1-5/8"

$549.99 $649.99

Hedman 69840 Elite Ultra-Duty HTC Coated Full Length Headers 1988-95 Chevy/GMC P/U 1500/2500/3500 5.0/5.7L Tube Size: 1-5/8"

GM Trucks/Vans/Motorhomes

  • Without smog injection or injection heads.
  • Modification to stock exhaust required to retain catalytic converter.
  • Not legal for sale or use in California on pollution controlled motor vehicles.
  • Must modify rotary A/C bracket.
  • Late model chassis. Engine offset to passenger side of vehicle.
  • Elite replacement gasket #500-27520.

    •

    Specifications:

    Application
    Automotive
    Bolts/Studs Included
    Yes
    Catalytic Converter(s) Included
    No
    Collector Attachment
    Ball and socket flange
    Cross Over Pipe Included
    No
    Cylinder Head Port Shape
    Oval
    Flange Style
    Standard
    Gaskets Included
    Yes
    Header Finish
    Thermal coated
    Header Material
    Steel
    Header Style
    Full-length
    Motor Mounts Included
    No
    Primary Tube Gauge
    14-gauge
    Quantity
    Sold as a pair
    Reducers Included
    Yes
    Transmission Mount Included
    No
    Tube Direction
    Down Swept
    Tuned
    No
    Weld-Up
    No
    Collector Diameter
    3 in (76.2 mm)
    Primary Tube Diameter
    1.625 in (41.3 mm)
    Manufacturer's Part Number:
    69840
    Shipping Weight:
    37.75
