Hedman Husler Muscle Rods LS Engine Swap Headers 45690
Regular price
$499.95
Sale price
$564.99
Headers, Husler®, Muscle Rods LS Engine Swap, Long Tube, Steel, Temporary Paint, for use with 4L60E/4L80E Transmission. Chevy, GMC, Pair
1975 -1986 C10 AND SBC
Brand:
Manufacturer's Part Number:
45690
Part Type:
Product Line:
Summit Racing Part Number:
HED-45690
UPC:
732611456906
Header Style:
Long tube one-piece
Header Material:
Steel
Primary Tube Outside Diameter (in.):
1 7/8 in.
Header Color:
Temporary non-high temperature paint
Flange Style:
Standard
Weld-Up:
No
Cylinder Head Port Shape:
Round
Collector Attachment:
Slip fit
Collector Diameter (in.):
3.00
Collector Reducers Included:
Yes
Collector Reducer Exit Diameter:
2.500 in.
Tuned:
No
Primary Tube Gauge:
18-gauge
Flange Thickness (in.):
0.38 in.
Bolts/Studs Included:
Yes
Gaskets Included:
Yes
Crossover Pipe Included:
No
Catalytic Converter(s) Included:
No
Motor Mounts Included:
No
Transmission Mount Included:
No
Quantity:
Sold as a pair.
Notes:
Designed to work with 4L60E, 4L65E, 4L80E transmissions. Tabs will need trimmed. NAL-19212593 oil pan required. The paint applied to these headers is a temporary coating only and is designed to burn off during use. High temperature paint or other high temperature coatings are recommended.
Hedman Husler Muscle Rods LS Engine Swap Headers
Hedman Husler Muscle Rods LS engine swap headers are specifically designed for the installation of LS Series engines into earlier model vehicles. Constructed from mandrel-bent, 18-gauge steel tubing and available uncoated or coated with Hedman's heat-resistant HTC or Black Maxx finish, Husler LS engine swap headers come with gaskets and hardware.
